Product Details
Place of Origin: China
Brand Name: CPET
Model Number: CP-3033
Payment & Shipping Terms
Minimum Order Quantity: 2sets
Price: 8300dollars/set
Packaging Details: Wooden case packing
Delivery Time: 35 work days
Payment Terms: D/A
Supply Ability: 30sets/month
Power Of Single Channel: |
400W/CH |
Quantity Of Load Channels: |
96CH |
External Dimension (L*W*H): |
2050*1000*1900 |
Power Of Single Channel: |
400W/CH |
Quantity Of Load Channels: |
96CH |
External Dimension (L*W*H): |
2050*1000*1900 |
Application Scope
Suitable for aging of adapters, industrial power supplies, LED power supplies, server power supplies, communication power supplies, SSN, NPS power supplies, etc.
Outstanding functions
1. Set the load parameters and monitor the voltage, current, power and other parameters in real time.
2. CC, CV, CR load mode.
3. In CC load mode, channels can be connected in parallel to meet the product power expansion.
4. Built-in automatic protection device for overtemperature and smoke alarm.
5. Editable switch timing, load conversion function.
6. Energy saving conversion efficiency above 85%.
7. Use with power aging monitoring software.
8. Temperature monitoring function in product area (optional).
9. Energy saving conversion efficiency above 85%.
Performance parameters
| Model | CP-3033 | CP-3034 |
| Power of single channel | 400W/CH | 1600W/CH |
| Quantity of load channels | 96CH | 36CH |
| Scope of load voltage | 3-60V | 3-60V |
| Scope of load current | 0.5-40A/CH | 0.5-120A/CH |
| Load precision | ±(2%+0.5%FS) | |
| Load Model | Energy saving load module | |
| Load Mode | CC+CV+CR Mode | |
| Number for plies of product zone | 6 | |
| Height for plies of product zone(mm) | 170 | |
| Width of products zone(mm) | 340 | |
| Temperature control of products zone | Temperature control tyep of products zone: normal temperature-60°C | |
| Structure material of trolley | Elaborately processed and produced with cold-rolled sheet | |
| Mode of main control | Monitoring software for burn-in of computermonitoring type power | |
| Input mode of UUT | Multi-purpose socket/speaker wire clip/custom design | |
| Interface mode of UUT | Connecting fixture boards(with various specifications)for first choice/custom design | |
| External dimension | 2050*1000*1900/custom design | |
