Product Details
Place of Origin: China
Brand Name: CPET
Model Number: CP-301903
Payment & Shipping Terms
Minimum Order Quantity: 2sets
Price: 8300dollars/set
Packaging Details: Wooden case packing
Delivery Time: 35 work days
Supply Ability: 30sets/month
Warranty: |
Free Parts Warranty For 1 Year |
Scope Of Load Current: |
0.5-10A/CH |
External Dimension (L*W*H): |
2050*880*1900 |
Warranty: |
Free Parts Warranty For 1 Year |
Scope Of Load Current: |
0.5-10A/CH |
External Dimension (L*W*H): |
2050*880*1900 |
Ageing Rack For High-Power Mobile Power Circuit Board Made In China
| Model | CP-301903 |
| Power of single channel | 100W/CH |
| Quantity of load channels | 60-120CH |
| Scope of load voltage | 2-450V |
| Scope of load current | 0.5-10A/CH |
| Load precision | ±(1%+0.1%FS) |
| Load Model | Energy Saving |
| Load Mode | CC+CV+CR+CP+LED Mode |
| Number for plies of product zone |
4 |
| Height for plies of product zone(mm) |
260 |
| Width of products zone(mm) |
300 |
| Temperature control of products zone |
Temperature control type of products zone: normal temperature-60℃ |
| Structure material of trolley |
Elaborately processed and produced with cold-rolled sheet |
| Mode of main control | Monitoring software for burn-in of computer-monitoring type power |
| Input mode of UUT | Multi-purpose socket/speaker wire clip/custom design |
| Interface mode of UUT | Connecting fixture boards (with various specifications) for first choice/custom design |
| External dimension (L*W*H) |
2050*880*1900 |
